Dual-Monitor Thunderbolt 3 to HDMI Adapter (M/2xF) - 4K 60 Hz, 4:4:4, Silver
| Product Name |
Eaton Tripp Lite series multi-port adapter
|
| Catalog Number |
MTB3-002-HD
|
| UPC |
037332254832
|
| Product Length/Depth |
6.5 in
|
| Product Height |
1 in
|
| Product Width |
5.2 in
|
| Product Weight |
0.21 lb
|
| Compliances |
RoHS
|
| Global Catalog |
MTB3-002-HD
|
| Product Type |
Multi-port adapter
|
| Application |
|
| Type |
Video Adapter
|
| Operating Humidity Range |
10% to 90% RH (No Condensation)
|
| Storage Humidity Range |
10% to 90% RH (No Condensation)
|
| Color |
Gray
|
| Cable Jacket Rating |
VW-1
|
| Connector Plating |
Nickel
|
| Product Features |
Extended Mode
DisplayPort Alt Mode EDID Compatible Bus Powered 3D Video Supported Mirror Mode Multi-Resolution Support |
| USB Specification |
USB 3.0 (up to 5 Gbps)
USB 3.1 Gen 1 (up to 5 Gbps) USB 3.2 Gen 1 (up to 5 Gbps) |
| Cable Jacket Material |
PVC
|
| Color Depth |
36-bit Deep color
36-bit Deep Color |
| Chroma Sub Sampling |
4:2:2
4:4:4 |
| Plug Color |
White
Blue |
| HDCP Specification |
2.2
|
| SideA Connector1 |
THUNDERBOLT 3 (Type-C MALE)
|
| SideB Connector1 |
HDMI (FEMALE)
|
| SideB Connector2 |
HDMI (FEMALE)
|
| SideB Connector3 |
HDMI (FEMALE)
|
| Host Connector |
THUNDERBOLT 3 (Type-C MALE)
|
| Technology |
HDMI
Thunderbolt |
| Features |
Flex Center
|
| Video Ports Details |
|
| Supported Resolution |
3840x2160 (4K)
1920x1080 (1080p) 1280x720 (720p) |
| Number of USB Hub Ports |
0
|
| Storage Temperature Range |
14° to 113°F (-10° to 45°C)
|
| Max Supported Video Resolution |
3840 x 2160 (4K) @ 60Hz
|
| Thunderbolt Specification |
Thunderbolt 3 (up to 40Gbps short or active cables)
|
| Video Input |
THUNDERBOLT 3 (Type-C MALE)
|
| Video Output |
HDMI (FEMALE)
|
| Video Ports |
HDMI (FEMALE)
HDMI 2.0 HDCP 2.2 HDCP 1.4 |
Product specifications
